    Quick View
    Compare
    Deep Boring Tools with Boring Bar and TPGX09 Cartridge
    Micro Boring Head

    Deep Boring Tools with Boring Bar and TPGX09 Cartridge
    Read more
    Quick View
    Tool Included:
    Adaptable Insert
    TPGX0902

    Ordering code Shank/adaptor
    BTBH1680 BT40 (M16X2)
    BTBH2075 BT40 (M16X2)
    BTBH25100 BT40 (M16X2)
    BTBH2085 BT40 (M16X2)
    1. Deep Boring Tools in Shank Dia 16, 20 and 25 mm which holds Cartridges such as TPGX09,used for deeper boring operations using our Boring Heads like Dia 80, Dia 75 and Dia 100 mm Units. 2. Working length including cartridge can be 117 mm for entry Dia 26.25 mm. 3. The adjustment and maximum bore size will depend on the base boring head type used. INSTRUCTION MANUAL - Please follow the instructions given with the kit to ensure proper usage and prevent damage Additional information: Shank/ Adaptor: R8/M1TR (M12X1.5), MT3 (M12X1.75), ISO30 (M12X1.75) ISO DIN 2080, ISO40 (M16) ISO DIN 2080, ISO50 (M24) ISO DIN 2080, BT40 (M16) BT- MAS 403, BT50 (M24) BT- MAS 403, CAT40 (5/8”) CAT ANSI B5.50
    Quick View
  • Read more
    Quick View
    Compare
    ER Collets (DIN6499) ER8- ER50
    Collets

    ER Collets (DIN6499) ER8- ER50
    Read more
    Quick View
    Tool Included:

    Ordering Code

    Shank/Adaptor
    1. Complete range from ER8 to ER50 Collets are available. 2. Made from European Spring Steel, ER Collets come with a standard precision of 0.010 to 0.012 mm run-out. 3. High-Precision collets with 0.008 mm run-out are also available on request. 4. All ER collets are properly hardened to ensure rigidity and enhance life. 5. The ER collets are designed to clamp from 0.5 mm to 1 mm depending on the size. INSTRUCTION MANUAL: Please follow the instructions given with the kit to ensure proper usage and prevent damage Additional information:
    Shank/ Adaptor BT40 (M16) BTMAS 403, CAT40 (5/8”) CAT ANSI B5.50, BT50 (M24) BTMAS 403
    Quick View
  • Read more
    Quick View
    Compare
    Expansion Collets
    Collets

    Expansion Collets
    Read more
    Quick View
    Tool Included
    Ordering Code Shank/Adaptor
     1. Expansion Collets used for holding tubes for machining. 2. Ideal for center to center machining on long tubes, pipes 3. Customisation can be done based on drawing provided by user 4. Made from European Spring Steel 5. All collets are properly hardened to ensure rigidity and enhance life. INSTRUCTION MANUAL: Please follow the instructions given with the kit to ensure proper usage and prevent damage Additional information
    Shank/ Adaptor BT40 (M16) BTMAS 403, CAT40 (5/8”) CAT ANSI B5.50, BT50 (M24) BTMAS 403
    Quick View
  • Read more
    Quick View
    Compare
    Finish Boring Bar CAT40 with Micro Boring Unit TPGX09
    Micro Boring Head

    Finish Boring Bar CAT40 with Micro Boring Unit TPGX09
    Read more
    Quick View
    Tool Included
    Adaptable insert
    TPGX0902

    Ordering code Shank/adaptor
    BTFBB-BT40-100L BT40 (M16X2)
    BTFBB-CAT40-100L CAT40 (5/8")
    BTFBB-BT50-100L BT50 (M24)
    1. Finish Boring Bar with Micro Boring Unit TPGX09/ TCMT09 are ideal for production or batch operations in NC controlled machines. 2. Working length can be from 50-200 mm depending on boring size required and machine spindle taper. 3. The adjustment is 0.002 mm on the diameter thus allowing for precision bores to made. 4. The boring range is plus minus 0.5 mm. 5. Tapers available are BT40, CAT40, SK40, BT50, CAT50, SK50 INSTRUCTION MANUAL- Please follow the instructions given with the kit to ensure proper usage and prevent damage Additional Information:
    Shank/ Adaptor R8/M1TR (M12X1.5), MT3 (M12X1.75), ISO30 (M12X1.75) ISO DIN 2080, ISO40 (M16) ISO DIN 2080, ISO50 (M24) ISO DIN 2080, BT40 (M16) BT- MAS 403, BT50 (M24) BT- MAS 403, CAT40 (5/8”) CAT ANSI B5.50
    Quick View
  • Read more
    Quick View
    Compare
    Finish Boring Head 6-85 mm with Finish Cartridge, Modular Adaptor and Set of Indexable Tools- 5 Micron
    Micro Boring Head

    Finish Boring Head 6-85 mm with Finish Cartridge, Modular Adaptor and Set of Indexable Tools- 5 Micron
    Read more
    Quick View
    Tool Included
    Boring range (mm) Boring hole(mm) Graduation Tools shank dia 16 mm Finish cartridge
    6-85 16 1 div.= 0.005 Set of 6 Indexable Tools TPGX09/ CCMT09

    Boring range (mm) Boring length(mm) Adaptable insert
    6-10 18 WCGT02
    8-12 24 WCGT02
    10-14 40 TPGX0902
    12-100 48 TPGX0902
    16-10 64 TPGX0902
    20-85 72 TPGX0902

    Ordering code Shank/adaptor
    BTBH1262-5M-BT40-IT6 BT40 (M16) BTMAS 403
    BTBH1262-5M-CAT40-IT6 CAT40 (5/8”) CAT ANSI B5.50
    BTBH1262-5M-BT50-IT6 BT50 (M24) BTMAS 403
    1. Finish Boring Head Dia 62 mm with a boring capacity of 6- 85 mm is an ideal unit for production operations requiring repeatability for batch production jobs. 2. The Unit come with a Finish Cartridge in TPGX09/ TCMT09 or CCMT09. 3. With a single vertical holes of 16 mm, the unit can take tools with shank dia 16 mm (right hand tools). 4. The lead screw has an adjustment of 0.005 mm per division which gives an adjustment of 10 microns on the diameter. 5. The unit is hardened and ground to ensure sturdity and increased longevity 6. It comes pre-fitted with a Modular Taper Shank like BT40, BT50, SK40, SK50 or HSK Tapers, with working length from 70 to 200 mm, as per requirement. 7. The Boring Kit comes with 6 nos. Right Hand Indexable Tools (WCGT02/TPGX0902) with shank Dia 16 mm. 8. WCGT02 Entry Dia 6 X Boring Length 18 mm- 1 Nos. 9. WCGT02 Entry Dia 8 X Boring Length 24 mm- 1 Nos. 10.TPGX09 Entry Dia 10 mm X Boring Length 40 mm- 1 nos. 11. TPGX09 Entry Dia 12 mm X Boring Length 48 mm- 1 nos. 12.TPGX09 Entry Dia 16 mm X Boring Length 64 mm- 1 nos. 13.TPGX09 Entry Dia 20 mm X Boring Length 72 mm- 1 nos. 14.Inserts are to be purchased separately depending on the material to be machined. INSTRUCTION MANUAL- Please follow the instructions given with the kit to ensure proper usage and prevent damage Additional information
    Shank/ Adaptor BT40 (M16) BTMAS 403, CAT40 (5/8”) CAT ANSI B5.50, BT50 (M24) BTMAS 403
    Quick View
  • Read more
    Quick View
    Compare
    High Precision Micro Boring Head ‘MuBore-85’ 6-245 mm mm with Shank and Indexable Tools (2 Micron)
    Micro Boring Head

    High Precision Micro Boring Head ‘MuBore-85’ 6-245 mm mm with Shank and Indexable Tools (2 Micron)
    Read more
    Quick View
    Tool Included
    Boring range (mm) Boring hole(mm) Graduation Tools shank dia 12 mm
    6-245 mm 20 1 Div.= 0.02 Main Scale 1 Div.= 0.002 mm using Vernier Scale Set of 7 Indexable Tools
    Boring range (mm) Boring length(mm) Adaptable insert
    6-10 29 WCGT02
    8-12 37 WCGT02
    10-14 40 TPGX0902
    12-16 50 TPGX0902
    16-50 60 TPGX0902
    20-125 75 TPGX0902
    125=245 N/A TPGX11

    Ordering code Shank/adaptor
    BTBH2085-2M-BT40-IT6 BT40 (M16) BTMAS 403
    BTBH2085-2M-CAT40-IT6 CAT40 (5/8”) CAT ANSI B5.50
    BTBH2085-2M-BT50-IT6 BT50 (M24) BTMAS 403
    1. Ideally made for NC controlled machines, High Precision Micro Boring Head Dia 85 mm with a boring capacity of 6- 245 mm is a versatile unit and is a must for any Tool Room workshop. 2. With two vertical holes of 20 mm, the unit can take tools with shank dia 20 mm (right hand tools) and one can also use the horizontal hole (with a left hand tool) for making larger bores. 3. The lead screw has an adjustment of 0.02 mm per division on the Main Scale which can be used to make adjustments of 40 micron on the diameter. Using the Vernier scale, adjustments of 0.004 or 4 micron can also be made on the diameter. gives an adjustment of 10 microns on the diameter. 4. It comes pre-fitted with a taper shank such as BT40, BT50, CAT40, CAT50,, SK40, SK50, as per requirement. 5. The unit is hardened and ground to ensure sturdity and increased longevity 6. The Boring Kit comes with 6 nos. Right Hand Indexable Tools (WCGT02/TPGX0902) with shank Dia 20/12 mm and a Horizontal Tool for making larger bores: 7. WCGT02 Dia 12 mm: 1. Entry Dia 6 X Boring Length 29 mm- 1 Nos. 2. Entry Dia 8 X Boring Length 37 mm- 1 Nos. 8. TPGX09 Dia 20 mm 1. Entry Dia 10 mm X Boring Length 40 mm- 1 nos. 2. Entry Dia 12 mm X Boring Length 50 mm- 1 nos. 9. Entry Dia 16 mm X Boring Length 60 mm- 1 nos. 3. Entry Dia 125 mm- 1 nos. 10.Inserts are to be purchased separately depending on the material to be machined. INSTRUCTION MANUAL- Please follow the instructions given with the kit to ensure proper usage and prevent damage. Additional Information
    Shank/ Adaptor BT40 (M16) BTMAS 403, CAT40 (5/8”) CAT ANSI B5.50, BT50 (M24) BTMAS 403
    Quick View
  • Read more
    Quick View
    Compare
    High Precision Micro Boring Head 6-125 mm with Shank and Indexable Tools (5 Micron)
    Micro Boring Head

    High Precision Micro Boring Head 6-125 mm with Shank and Indexable Tools (5 Micron)
    Read more
    Quick View
    Tool Included
    Boring range (mm) Boring hole(mm) Graduation Tools shank dia 12 mm
    6-245 20 1 Div.= 0.005 Set of 6 Indexable Tools

    Boring range (mm) Boring length(mm) Adaptable insert
    6-10 29 WCGT02
    8-12 37 WCGT02
    10-14 40 TPGX0902
    12-100 50 TPGX0902
    16-10 60 TPGX0902
    92-125 N/A TPGX0902

    Ordering code Shank/adaptor
    BTBH1262-5M-BT40-IT6 BT40 (M16) BTMAS 403
    BTBH1262-5M-CAT40-IT6 CAT40 (5/8”) CAT ANSI B5.50
    BTBH1262-5M-BT50-IT6 BT50 (M24) BTMAS 403
    1. High Precision Micro Boring Head Dia 62 mm with a boring capacity of 6- 125 mm is a versatile unit and is a must for any Tool Room workshop. 2. With two vertical holes of 12 mm, the unit can take tools with shank dia 12 mm (right hand tools) and one can also use the horizontal hole (with a left hand tool) for making larger bores. 3. The lead screw has an adjustment of 0.005 mm per division which gives an adjustment of 10 microns on the diameter. 4. It comes pre-fitted with a taper shank as per requirement. 5. The unit is hardened and ground to ensure sturdity and increased longevity 6. The Boring Kit comes with 5 nos. Right Hand Indexable Tools (WCGT02/TPGX0902) with shank Dia 12 mm and a Horizontal Tool for making larger bores: 7. WCGT02: 1. Entry Dia 6 X Boring Length 29 mm- 1 Nos. 2. Entry Dia 8 X Boring Length 37 mm- 1 Nos. 8. TPGX09 1. Entry Dia 10 mm X Boring Length 40 mm- 1 nos. 2. Entry Dia 12 mm X Boring Length 50 mm- 1 nos. 9. Entry Dia 16 mm X Boring Length 60 mm- 1 nos. 3. Entry Dia 92 mm- 1 nos. 10.Inserts are to be purchased separately depending on the material to be machined. INSTRUCTION MANUAL-Please follow the instructions given with the kit to ensure proper usage and prevent damage Additional information
    Shank/ Adaptor BT40 (M16) BTMAS 403, CAT40 (5/8”) CAT ANSI B5.50, BT50 (M24) BTMAS 403
    Quick View
  • Read more
    Quick View
    Compare
    High Precision Micro Boring Head 6-245 mm with Indexable Tools (2 Micron)
    Micro Boring Head

    High Precision Micro Boring Head 6-245 mm with Indexable Tools (2 Micron)
    Read more
    Quick View
    Tool Included
    Boring range (mm) Boring hole(mm) Graduation Tools shank dia 12 mm
    6-245 20 1 Div.= 0.02 mm/ 0.002 mm Set of 7 Indexable Tools

    Boring range (mm) Boring length(mm) Adaptable insert
    6-10 29 WCGT02
    8-12 37 WCGT02
    10-14 40 TPGX0902
    12-100 50 TPGX0902
    16-150 60 TPGX0902
    20-150 80 TPGX0902
    135-245 N/A TPGX11

    Ordering code Shank/adaptor
    BTBH1262-5M-BT40-IT6 BT40 (M16) BTMAS 403
    BTBH1262-5M-CAT40-IT6 CAT40 (5/8”) CAT ANSI B5.50
    BTBH1262-5M-BT50-IT6 BT50 (M24) BTMAS 403
    1. High Precision Micro Boring Head Dia 85 mm (MuBore-85) with a boring capacity of 6- 245 mm is a study unit ideal for die moulding and precision boring applications. 2. With two vertical holes of 20 mm, the unit can take tools with shank dia 20 mm (right hand tools) and one can also use the horizontal hole (with a left hand tool) for making larger bores. 3. The lead screw has an adjustment of 0.02 mm per division which gives an adjustment of 40 microns on the diameter. Using the vernier scale, adjustment of 0.002 mm can be made which gives an adjustment of 0.004 mm (4 micron) diamterically. 4. It comes pre-fitted with a taper shank as per requirement. 5. The unit is hardened and ground to ensure sturdity and increased longevity 6. The Boring Kit comes with 6 nos. Right Hand Indexable Tools (WCGT02/TPGX0902) with shank Dia 20 mm and a TPGX11 Horizontal Tool for making larger bores: 7. WCGT02: 1. Entry Dia 6 X Boring Length 29 mm- 1 Nos. 2. Entry Dia 8 X Boring Length 37 mm- 1 Nos. 8. TPGX09 1. Entry Dia 10 mm X Boring Length 40 mm- 1 nos. 2. Entry Dia 12 mm X Boring Length 50 mm- 1 nos. 9. Entry Dia 16 mm X Boring Length 60 mm- 1 nos. 10. Entry Dia 20 mm X Boring Length 80 mm- 1 nos. 11. TPGX11 Entry Dia 135 mm- 1 nos. 12. Inserts are to be purchased separately depending on the material to be machined INSTRUCTION MANUAL- Please follow the instructions given with the kit to ensure proper usage and prevent damage Additional information
    Shank/ Adaptor BT40 (M16) BTMAS 403, CAT40 (5/8”) CAT ANSI B5.50, BT50 (M24) BTMAS 403
    Quick View
  • Read more
    Quick View
    Compare
    Micro Boring Head 10-125 mm
    Micro Boring Head

    Micro Boring Head 10-125 mm
    Read more
    Quick View
    Tool Included
    Boring range (mm) Boring hole(mm) Graduation Tools shank dia 12 mm
    10-125 12 1 Div.= 0.01 Set of 3 Indexable Tools

    Boring range (mm) Boring length (mm0 Adaptable insert
    10-12 40 TPGX0902
    12-100 50 TPGX0902
    92-125 N/A TPGX0902

    Ordering code Shank/adaptor
    BTBH1262-R8-IT3R8 R8/M1TR (M12X1.5)
    BTBH1262-MT3-IT3 MT3 (M12X1.75)
    BTBH1262-ISO30- IT3 ISO30 (M12X1.75) ISO DIN 2080
    BTBH1262-ISO40- IT3 ISO40 (M16) ISO DIN 2080
    BTBH1262-BT40- IT3 BT40 (M16) BTMAS 403
    BTBH1262-CAT40- IT3 CAT40 (5/8”) CAT ANSI B5.50
    Dia 62 mm Micro Boring Head Kit with a boring capacity of 10- 125 mm is a versatile unit and is a must for any Tool Room workshop. 1. With two vertical holes of 12 mm, the unit can take tools with shank dia 12 mm (right hand tools) and one can also use the horizontal hole (with a left hand tool) for making larger bores. 2. The lead screw has an adjustment of 0.01 mm per division which gives an adjustment of 20 microns on the diameter. 3. It comes pre-fitted with a taper shank as per requirement. 4. The unit is hardened and ground to ensure sturdity and increased longevity 5. The Boring Kit comes with 2 nos. Right Hand Indexable Tools (TPGX0902) with shank Dia 12 mm and a Left Hand Tool 1. Entry Dia 10 mm X Boring Length 40 mm- 1 nos. 2. Entry Dia 12 mm X Boring Length 50 mm- 1 nos. 3. Entry Dia 92 mm TPGX0902- 1 nos. 6. Inserts are to be purchased separately depending on the material to be machined. INSTRUCTION MANUAL- Please follow the instructions given with the kit to ensure proper usage and prevent damage Additional information:
    Shank/ Adaptor R8/M1TR (M12X1.5), MT3 (M12X1.75), ISO30 (M12X1.75) ISO DIN 2080, ISO40 (M16) ISO DIN 2080, BT40 (M16) BT- MAS 403, CAT40 (5/8”) CAT ANSI B5.50
    Quick View
  • Read more
    Quick View
    Compare
    Micro Boring Head 10-180 mm with 5 nos. TPGH09/11 Indexable Tool
    Micro Boring Head

    Micro Boring Head 10-180 mm with 5 nos. TPGH09/11 Indexable Tool
    Read more
    Quick View
    Tool Included
    Boring range (mm) Boring hole(mm) Graduation Tools shank dia 20 mm
    10-175 20 1 Div.= 0.01 TPGH09 Boring Bar R/H- 4 nos. TPGH11 Boring Bar L/H- 1 nos.

    Boring range (mm) Boring length(mm) Adaptable insert
    10-12 40 TPGX0902
    12-16 48 TPGX0902
    16-50 64 TPGX0902
    20-125 74 TPGX0902
    105-175 N/A TPGX1102
    Ordering code Shank/Adaptor
    BTBH2075-R8-IT5 R8/M1TR (M12×1.5)
    BTBH2075-MT3-IT5 MT3 (M12×1.75)
    BTBH2075-ISO30-IT5 ISO30 (M12×1.75) ISO DIN 2080
    BTBH2075-ISO40-IT5 ISO40 (M16) ISO DIN 2080
    BTBH2075-ISO50-IT5 ISO50 (M24) ISO DIN 2080
    BTBH2075-BT40-IT5 BT40 (M16) BT–MAS 403
    BTBH2075-BT50-IT5 BT50 (M24) BT–MAS 403
    BTBH2075-CAT40-IT5 CAT40 (5/8”) CAT ANSI B5.50
    1.Dia 75 mm Micro Boring Head Kit is a sturdy unit for boring large diameters. It can be used to bore sizes from 10 mm to up to 175 mm using a set of TPGX09/TPGX11 Indexable Tools. 2. This is very useful for boring deeper bores with depths of up to 80 mm. 3. The slide is hardened and ground which ensures its stable and sturdy and also increases the longevity of the unit. 4. There are two vertical holes and a horizontal hole of 20 mm. The vertical holes can take tools of shank dia 20 mm and bore from 10 mm to up to 125 mm. With an offset of 25 mm, the unit can bore a maximum diameter of 150 mm using a left hand tool in the horizontal hole. 5. The lead screw has an adjustment of 0.01 mm per division which gives and adjustment of 20 micron on the diameter. 6. It comes pre-fitted with a taper shank as per requirement. 7. The boring kit comes with 4 nos. Dia 20 mm TPGX09 Right Hand Tools and 1 Nos. TPGX1102 Left Hand Tool: 1. Entry Dia 10 mm X Boring Length 40 mm TPGX0902- 1 nos. 2. Entry Dia 12 mm X Boring Length 48 mm TPGX0902- 1 nos. 3. Entry Dia 16 mm X Boring Length64 mm TPGX0902- 1 nos. 4. Entry Dia 20 mm X Boring Length 80 mm TPGX0902- 1 nos. 5. Entry Dia 105 mm TPGX1102- 1 nos. Inserts are to be purchased separately depending on the material to be machined. INSTRUCTION MANUAL- Please follow the instructions given with the kit to ensure proper usage and prevent damage Additional information
    Shank/ Adaptor R8/M1TR (M12X1.5), MT3 (M12X1.75), ISO30 (M12X1.75) ISO DIN 2080, ISO40 (M16) ISO DIN 2080, ISO50 (M24) ISO DIN 2080, BT40 (M16) BT- MAS 403, BT50 (M24) BTMAS 403, CAT40 (5/8”) CAT ANSI B5.50
    Quick View
  • Read more
    Quick View
    Compare
    Micro Boring Head 10-80 mm
    Micro Boring Head

    Micro Boring Head 10-80 mm
    Read more
    Quick View
    Tool Included
    Boring range (mm) Boring hole(mm) Graduation Tools shank dia 12 mm
    10-80 12 1 Div.= 0.02 TPGX09 Boring Tools – 2 nos.

    Ordering code Shank/Adaptor
    BTBH1250-R8-IT2 R8/M1TR (M12×1.5)
    BTBH1250-ISO30-IT2 ISO30 (M12×1.75) ISO DIN 2080
    BTBH1250-ISO40-IT2 ISO40 (M16) ISO DIN 2080
    BTBH1250-ISO50-IT2 ISO40 (M24) ISO DIN 2080
    BTBH1250-MT2-IT2 MT2 (M10)
    BTBH1250-MT3-IT2 MT3 (M12×1.75)
    BTBH1250-BT40-IT2 BT40 (M16×2)
    BTBH1250-BT50-IT2 BT50 (M24)
    BTBH1250-CAT40-IT2 CAT40 (5/8”)
    1.Dia. 50 mm Micro Boring Head Kit, also known as a C Type Boring Head, with a boring capacity of 10-80 mm, is a globally used model 2. The unit can take tools with shank Dia 12 mm (right hand tools) and is very useful to bore holes which are not too deep. 3. The lead screw has an adjustment of 0.02 mm per division which gives an adjustment of 40 microns on the diameter. 4. It comes pre-fitted with a taper shank such as R8, ISO30, ISO40, Mt2, MT3, BT30, BT40, BT50 or straight Shank 25 mm and 32 mm, as per requirement. 5. The slide is hardened and ground to ensure sturdity and increased longevity. 6. The Boring Kit comes with 2 nos. Right Hand Indexable Tools (TPGX0902) with shank Dia 12 mm 1. Entry Dia 10 mm X Boring Length 40 mm- 1 nos. 2. Entry Dia 12 mm X Boring Length 50 mm- 1 nos. 7. Inserts are to be purchased separately depending on the material to be machined. INSTRUCTION MANUAL- Please follow the instructions given with the kit to ensure proper usage and prevent damage Additional information:
    Shank/ Adaptor :R8/M1TR (M12X1.5), ISO30 (M12X1.75) ISO DIN 2080, ISO40 (M16) ISO DIN 2080, MT2 (M10), MT3 (M12X1.75)
    Quick View
  • Read more
    Quick View
    Compare
    Placeholder
    Micro Boring Head

    Micro Boring Head 16-150 mm
    Read more
    Quick View
    Tool Included
    Boring range (mm) Boring hole(mm) Graduation Tools shank dia 16 mm
    16-150 16 1 Div.= 0.01 TPGH09 Boring Bar R/H- 1 nos. CCMT09 Left Hand Boring Bar-1 nos.

    Boring range (mm) Boring length(mm) Adaptable insert
    16-150 48 TPGX0902
    125-150 N/A CCMT09

    Ordering code Shank/Adaptor
    BTBH1680-R8-IT2 R8/M1TR (M12×1.5)
    BTBH1680-MT3-IT2 MT3 (M12×1.75)
    BTBH1680-ISO30-IT2 ISO30 (M12×1.75) ISO DIN 2080
    BTBH1680-ISO40-IT2 ISO40 (M16) ISO DIN 2080
    BTBH1680-ISO50-IT2 ISO50 (M24) ISO DIN 2080
    BTBH1680-BT40-IT2 BT40 (M16) BT–MAS 403
    BTBH1680-BT50-IT2 BT50 (M24) BT–MAS 403
    BTBH1680-CAT40-IT2 CAT40 (5/8”) CAT ANSI B5.50
    BTBH1680-MT4-IT2 MT4 (M16×2)
    BTBH1680-MT5-IT2 MT5 (M24)
      1.Dia 80 mm Micro Boring Head Kit with a boring capacity of 16- 150 mm is a versatile unit and is a must for any Tool Room workshop. 2. With two vertical holes of 16 mm, the unit can take tools with shank dia 16 mm (right hand tools) and one can also use the horizontal hole (with a left hand tool) for making larger bores. 3. The lead screw has an adjustment of 0.01 mm per division which gives an adjustment of 20 microns on the diameter. 4. It comes pre-fitted with a taper shank as per requirement. 5. The unit is hardened and ground to ensure sturdity and increased longevity. 6. The Boring Kit comes with 2 nos. Right Hand Indexable Tools with shank Dia 16 mm 1. Entry Dia 16 mm X Boring Length 48 mm Right Hand- TPGX09- 1 nos. 2. Dia 16 mm CCMT09 Left Hand Tool- 1 nos.. 3. Inserts are to be purchased separately depending on the material to be machined. INSTRUCTION MANUAL- Please follow the instructions given with the kit to ensure proper usage and prevent damage Additional information
    Shank/ Adaptor R8/M1TR (M12X1.5), MT3 (M12X1.75), ISO30 (M12X1.75) ISO DIN 2080, ISO40 (M16) ISO DIN 2080, ISO50 (M24) ISO DIN 2080, BT40 (M16) BT- MAS 403, BT50 (M24) BT- MAS 403, CAT40 (5/8”) CAT ANSI B5.50
