Micro Boring Head 10-80 mm

 Home Metlartis  - Products - Micro Boring Head 10-80 mm
Micro Boring Head 10-80 mm
Micro Boring Head 10-80 mm - Image 2
Micro Boring Head 10-80 mm - Image 3
Micro Boring Head 10-80 mm - Image 4

Micro Boring Head 10-80 mm

Technical Specifications:

● Boring range (mm) 10-80
● Boring Hole (mm) 12
● Graduation 1 Div.= 0.02
● Tools Dia 12 (mm) TPGX09 Boring Tools – 2 nos.

Inclusions:

1. Micro Boring Head Dia 50 mm: 1 nos.
2. Shank (as per order/selection): 1 nos.
3. Boring Bars TPGX09 Dia 12 mm- 2 nos.
4. LN Keys: 2.5, 4 mm (1 each)
5. Torx Flag Keys T8

BTBH1250-IT2

Description

Tool Included

Boring range (mm) Boring hole(mm) Graduation Tools shank dia 12 mm
10-80 12 1 Div.= 0.02 TPGX09 Boring Tools – 2 nos.



Ordering code Shank/Adaptor
BTBH1250-R8-IT2 R8/M1TR (M12×1.5)
BTBH1250-ISO30-IT2 ISO30 (M12×1.75) ISO DIN 2080
BTBH1250-ISO40-IT2 ISO40 (M16) ISO DIN 2080
BTBH1250-ISO50-IT2 ISO40 (M24) ISO DIN 2080
BTBH1250-MT2-IT2 MT2 (M10)
BTBH1250-MT3-IT2 MT3 (M12×1.75)
BTBH1250-BT40-IT2 BT40 (M16×2)
BTBH1250-BT50-IT2 BT50 (M24)
BTBH1250-CAT40-IT2 CAT40 (5/8”)

1.Dia. 50 mm Micro Boring Head Kit, also known as a C Type
Boring Head, with a boring capacity of 10-80 mm, is a globally
used model
2. The unit can take tools with shank Dia 12 mm (right hand tools)
and is very useful to bore holes which are not too deep.
3. The lead screw has an adjustment of 0.02 mm per division which
gives an adjustment of 40 microns on the diameter.
4. It comes pre-fitted with a taper shank such as R8, ISO30, ISO40, Mt2, MT3, BT30, BT40, BT50
or straight Shank 25 mm and 32 mm, as per requirement.
5. The slide is hardened and ground to ensure sturdity and
increased longevity.
6. The Boring Kit comes with 2 nos. Right Hand Indexable Tools
(TPGX0902) with shank Dia 12 mm
1. Entry Dia 10 mm X Boring Length 40 mm- 1 nos.
2. Entry Dia 12 mm X Boring Length 50 mm- 1 nos.
7. Inserts are to be purchased separately depending on the
material to be machined.

INSTRUCTION MANUAL- Please follow the instructions given with the
kit to ensure proper usage and prevent damage

Additional information:

Shank/ Adaptor :R8/M1TR (M12X1.5), ISO30 (M12X1.75) ISO DIN 2080, ISO40 (M16) ISO DIN 2080, MT2 (M10), MT3 (M12X1.75)
