High Precision Micro Boring Head ‘MuBore-85’ 6-245 mm mm with Shank and Indexable Tools (2 Micron)

 Home Metlartis  - Products - High Precision Micro Boring Head ‘MuBore-85’ 6-245 mm mm with Shank and Indexable Tools (2 Micron)
High Precision Micro Boring Head ‘MuBore-85’ 6-245 mm mm with Shank and Indexable Tools (2 Micron)
High Precision Micro Boring Head ‘MuBore-85’ 6-245 mm mm with Shank and Indexable Tools (2 Micron) - Image 2
High Precision Micro Boring Head ‘MuBore-85’ 6-245 mm mm with Shank and Indexable Tools (2 Micron) - Image 3
High Precision Micro Boring Head ‘MuBore-85’ 6-245 mm mm with Shank and Indexable Tools (2 Micron) - Image 4

High Precision Micro Boring Head ‘MuBore-85’ 6-245 mm mm with Shank and Indexable Tools (2 Micron)

Technical Specifications:

● Boring range (mm) 6-245 mm
● Boring Hole (mm) 20
● Graduation 1 Div.= 0.02/ 0.002 mm
● Tools Dia 12 (mm) Set of 7 Indexable Tools

Inclusions:

1. High Precision Micro Boring Head Dia 85 mm: 1 nos.
2. Shank (as per order/selection): 1 nos.
3. Boring Bars WCGT02/ TPGX09 Dia 20/12 mm- 7 nos.
4. LN Keys: 3, 4, 6 mm (1 each)
5. Torx Flag Keys: T6, T8

BTBH2085-2M-IT7

Description

Tool Included

Boring range (mm) Boring hole(mm) Graduation Tools shank dia 12 mm
6-245 mm 20 1 Div.= 0.02 Main Scale 1 Div.= 0.002 mm using Vernier Scale Set of 7 Indexable Tools
Boring range (mm) Boring length(mm) Adaptable insert
6-10 29 WCGT02
8-12 37 WCGT02
10-14 40 TPGX0902
12-16 50 TPGX0902
16-50 60 TPGX0902
20-125 75 TPGX0902
125=245 N/A TPGX11



Ordering code Shank/adaptor
BTBH2085-2M-BT40-IT6 BT40 (M16) BTMAS 403
BTBH2085-2M-CAT40-IT6 CAT40 (5/8”) CAT ANSI B5.50
BTBH2085-2M-BT50-IT6 BT50 (M24) BTMAS 403

1. Ideally made for NC controlled machines, High Precision Micro Boring
Head Dia 85 mm with a boring capacity of 6-
245 mm is a versatile unit and is a must for any Tool Room
workshop.
2. With two vertical holes of 20 mm, the unit can take tools with
shank dia 20 mm (right hand tools) and one can also use the
horizontal hole (with a left hand tool) for making larger bores.
3. The lead screw has an adjustment of 0.02 mm per division on the Main
Scale which can be used to make adjustments of 40 micron on the
diameter. Using the Vernier scale, adjustments of 0.004 or 4 micron can
also be made on the diameter.
gives an adjustment of 10 microns on the diameter.
4. It comes pre-fitted with a taper shank such as BT40, BT50, CAT40,
CAT50,, SK40, SK50, as per requirement.
5. The unit is hardened and ground to ensure sturdity and
increased longevity
6. The Boring Kit comes with 6 nos. Right Hand Indexable Tools
(WCGT02/TPGX0902) with shank Dia 20/12 mm and a Horizontal Tool for
making larger bores:
7. WCGT02 Dia 12 mm:
1. Entry Dia 6 X Boring Length 29 mm- 1 Nos.
2. Entry Dia 8 X Boring Length 37 mm- 1 Nos.

8. TPGX09 Dia 20 mm
1. Entry Dia 10 mm X Boring Length 40 mm- 1 nos.
2. Entry Dia 12 mm X Boring Length 50 mm- 1 nos.
9. Entry Dia 16 mm X Boring Length 60 mm- 1 nos.
3. Entry Dia 125 mm- 1 nos.
10.Inserts are to be purchased separately depending on the
material to be machined.

INSTRUCTION MANUAL- Please follow the instructions given with the
kit to ensure proper usage and prevent damage.

Additional Information

Shank/ Adaptor BT40 (M16) BTMAS 403, CAT40 (5/8”) CAT ANSI B5.50, BT50 (M24) BTMAS 403
