Finish Boring Head 6-85 mm with Finish Cartridge, Modular Adaptor and Set of Indexable Tools- 5 Micron
Finish Boring Head 6-85 mm with Finish Cartridge, Modular Adaptor and Set of Indexable Tools- 5 Micron - Image 2
Finish Boring Head 6-85 mm with Finish Cartridge, Modular Adaptor and Set of Indexable Tools- 5 Micron - Image 3
Finish Boring Head 6-85 mm with Finish Cartridge, Modular Adaptor and Set of Indexable Tools- 5 Micron - Image 4

Finish Boring Head 6-85 mm with Finish Cartridge, Modular Adaptor and Set of Indexable Tools- 5 Micron

Technical Specifications:

● Boring range (mm) 6-85
● Boring Hole (mm) 16
● Graduation 1 Div.= 0.005 mm
● Tools Dia 12 (mm) Set of 6 Indexable Tools

Inclusions:

1. Finish Boring Head Dia 62 mm: 1 nos.
2. Modular Shank (as per order/selection): 1 nos.
3. Finish Cartridge TPGX09/ CCMT09
4. Boring Bars WCGT02/ TPGX09 Dia 16 mm- 6 nos.
5. LN Keys: 3, 4, 6 mm (1 each)
6. Torx Flag Keys: T6, T8

BTBH1262-5M-IT6-1

Description

Tool Included

Boring range (mm) Boring hole(mm) Graduation Tools shank dia 16 mm Finish cartridge
6-85 16 1 div.= 0.005 Set of 6 Indexable Tools TPGX09/ CCMT09



Boring range (mm) Boring length(mm) Adaptable insert
6-10 18 WCGT02
8-12 24 WCGT02
10-14 40 TPGX0902
12-100 48 TPGX0902
16-10 64 TPGX0902
20-85 72 TPGX0902



Ordering code Shank/adaptor
BTBH1262-5M-BT40-IT6 BT40 (M16) BTMAS 403
BTBH1262-5M-CAT40-IT6 CAT40 (5/8”) CAT ANSI B5.50
BTBH1262-5M-BT50-IT6 BT50 (M24) BTMAS 403

1. Finish Boring Head Dia 62 mm with a boring capacity of 6-
85 mm is an ideal unit for production operations requiring repeatability
for batch production jobs.
2. The Unit come with a Finish Cartridge in TPGX09/ TCMT09 or CCMT09.
3. With a single vertical holes of 16 mm, the unit can take tools with
shank dia 16 mm (right hand tools).
4. The lead screw has an adjustment of 0.005 mm per division which
gives an adjustment of 10 microns on the diameter.
5. The unit is hardened and ground to ensure sturdity and
increased longevity
6. It comes pre-fitted with a Modular Taper Shank like BT40, BT50, SK40,
SK50 or HSK Tapers, with working length from 70 to 200 mm, as per
requirement.
7. The Boring Kit comes with 6 nos. Right Hand Indexable Tools
(WCGT02/TPGX0902) with shank Dia 16 mm.
8. WCGT02 Entry Dia 6 X Boring Length 18 mm- 1 Nos.
9. WCGT02 Entry Dia 8 X Boring Length 24 mm- 1 Nos.
10.TPGX09 Entry Dia 10 mm X Boring Length 40 mm- 1 nos.
11. TPGX09 Entry Dia 12 mm X Boring Length 48 mm- 1 nos.
12.TPGX09 Entry Dia 16 mm X Boring Length 64 mm- 1 nos.
13.TPGX09 Entry Dia 20 mm X Boring Length 72 mm- 1 nos.
14.Inserts are to be purchased separately depending on the
material to be machined.

INSTRUCTION MANUAL- Please follow the instructions given with the
kit to ensure proper usage and prevent damage

Additional information

Shank/ Adaptor BT40 (M16) BTMAS 403, CAT40 (5/8”) CAT ANSI B5.50, BT50 (M24) BTMAS 403
